PCL-VSI Crusher Overview

Sand Making Machine (Namely PCL Vertical shaft impact crusher) is of high-power and low-consumption, which is designed depending on several years- hard work and study of mechanical mining equipment. Sand Maker absorbed the advanced technology of the same products of Barmac Company of America, now is of the international level. Sand Making Machine plays an important role in crushing minerals into pieces.

PCL-VSI Crusher Application

PCL Vertical shaft impact crusher is widely used in all kinds of mineral, cement, corhart, bauxite chmotte, carborundum grain, glass raw material, machine made construction sand, stone stock and all kinds of metallurgy slag, especially carborundum, sintered bauxite, magnesite, and so on material with features of very hard and anticorrosion. And Sand Making Machine is more productive than other kind of crushers.

vsi crusher
Click here to watch more pictures about PCL-VSI Crusher!

PCL-VSI Crusher Working Principle

Stone less than 50mm enters sand making machine though conveyor belt. Stone is crushed by hitting other stones. Material falls down to impellor cavity. Under great centrifugal force, it hits material that coming downwards. After hitting each other, they force a vortex between impellor and shell, and hit each other several times, finally smaller stone comes out, and goes to vibrating screen. Satisfactory material is transported to sand washing machine, however overlarge material will go back to sand maker to be refreshed. Output sizes can be made according to customers requirement. If input size is larger than the designed size, other crushing equipment will be necessary.

PCL-VSI Crusher Features and Benefits

1. Simple structure and low operating cost
2. High efficiency and low consumption
3. Sand Making Machine has the function of fine crush and crude grinding
4. Slightly influenced by the moisture content of material, and the max moisture content is 8%
5. More suitable for crushing mid-hardness and high-hardness materials
6. Cubic shape of final products, high density of piling up and low iron pollution
7. More wearable and easy maintenance
8. Low working noise and light dust pollution

PCL-VSI Crusher Specifications

Model Max. feeding (mm) Power
Impeller speed
Outer dimension:
L-W-H (mm)
PCL-600 30 2-30 2000-3000 12-30 3000-1500-2050 5.6
PCL-750 35 2-45 1500-2500 25-55 3300-1800-2440 7.3
PCL-900 40 2-55 1200-2000 55-100 3600-2140-2620 12.1
PCL-900B 40 2-75 1000-1450 65-130 3600-2140-2620 13.6
PCL-1050 45 2-(90-110) 1000-1700 100-160 4480-2450-3906 16.9
PCL-1250 45 2-(132-180) 850-1450 160-300 4520-2640-3100 22
PCL-1350 50 2-(180-220) 800-1193 200-360 5340-2940-3650 26
